Operating Instructions ACU
12/16
Operation mode 530, 532,
554
Function
15 -
Warning current limitation
A controller or Operation Mode 573 of the intelligent current
limits limit the output current.
16 -
Controller current limit. long
term Ixt
The overload reserve for 60 s has been used up and the output
current is being limited.
17 -
Controller current limit.
short term Ixt
The overload reserve for 1 s has been used up and the output
current is being limited.
18 -
Controller current limit Tk
Max. heat sink temperature T
K
reached, intelligent current limits
of Operation Mode 573 active.
19 -
Controller current limit.
motor temp.
Max. motor temperature reached, intelligent current limits of
Operation Mode 573 active.
20 -
Comparator 1
The comparison according to the selected Op. Mode
Comparator 1 540 is true.
21 -
Comparator 2
The comparison according to the selected Op. Mode
Comparator 2 543 is true.
22 -
Warning V-belt
Warning of Operation Mode 581 of V-belt Montoring.
23 -
Timer 1
The selected Operation Mode Timer 1 790 generates an output
signal of the function.
24 -
Timer 2
The selected Operation Mode Timer 2 793 generates an output
signal of the function.
25 -
Warning mask
Message of the configurable parameter Create Warning Mask
536.
26 -
Warning, application
A warning application is signaled. Display of the actual value is
effected via parameter Application Warnings 273.
27 -
Warning mask, application
Message of the configurable parameter Create Appl. Warning
Mask 626.
28 -
Warning gen. + warning
appl.
A warning or warning application is signaled.
29 -
Warning mask gen. +
Warning mask appl.
Message of configurable parameters Create Warning Mask 536
and Create Appl. Warning Mask 626.
30 -
Flux forming finished
Magnetic field has been impressed.
41 -
Release brake
Activation of a brake unit depending on Operation Mode 620 for
the staring behavior, Operation Mode 630 for the stopping
behavior or the configured brake control system.
43 -
External fan
The Switch-On Temperature 39 was reached.
50 -
Synchronization Fault
1)
The phase error of the index control exceeded the Warning
Level 597.
51 -
Signal Fault
1)
Index signal period too short during index control.
56 -
Phasing Done
2)
Message of phasing function. For positioning in combination with
the function of the electronic gear, the value Phasing: Offset
1125 was reached.
57 -
In Gear
1) 2)
Synchronization of the electronic gear is reached. The slave
drive is engaged and operates at a synchronous angle with the
master.
58 -
Position Comparator
2)
The current actual value is in the range between On-Position
1243 to Off-Position 1244 of the position comparator. The set
value of parameter Hysteresis 1245 is considered.
59 -
Homing DONE
2)
Homing was started and the reference position for a positioning
operation was set.
