Bosch B4512 Installation Manual

Control Panels Appendix | en 135
Bosch Security Systems, Inc. Installation Manual 2018.07 | 16 | F.01U.287.180
Panel event Modem4 code
D6500 mode
Modem4 code
Bosch SIA mode
Contact ID event Contact ID code
Configuration Failure
(Device)
TssssD NpiddddEP System Peripheral Trouble 1 330 00 zzz
Configuration Failure
Restoral (Device)
RssssD NpiddddER System Peripheral Trouble
Restoral
3 330 00 zzz
Control panel battery low Tsss9 NYT Low System Battery 1 302 00 000
Control panel battery missing Tsss9 NYM Battery Missing/Dead 1 311 00 000
Control panel battery
restored to normal
Rsss9 NYR Low System Battery
Restore
3 302 00 000
Control panel off-line TsssF Nid5002TS System Shutdown 3 308 00 F02
Control panel on-line RsssF Nid5002TE System Shutdown Restore 3 308 00 F02
Create Status Report Sssss NYY Status Report to Follow 1 605 00 000
Date changed - no user
indentified
NsD07 NJD Time/Date Reset 1 625 00 000
Date changed by user NsD07 NidiiiiJD Time/Date Reset 1 625 00 uuu
Delete User by User NsD05 NidiiiiJXiiii Local Only Local Only
DNS Failure TsB01 NpiddddYS Communication Trouble 1 350 00
1
zzz
DNS Failure Restore NsB01 NpiddddYK Communication Trouble
Restore
3 350 00
1
zzz
Duplicate SDI2 device TsssD NpiddddET System Peripheral Trouble 1 330 aa iii
Duplicate SDI2 device
Restore
RsssD NpiddddER System Peripheral Trouble
Restore
3 330 aa iii
Duress Diiii Nriaa/idiiiiHA Duress 1 121 aa uuu
Equipment Fail TsD29 NpiddddIA System Peripheral Trouble 1 330 00
1
zzz
Equipment Restore RsD29 NpiddddIR System Peripheral Trouble
Restore
3 330 00
1
zzz
Event Log Overflow AsD01 NJO Event Log Overflow 1 624 00 000
Event Log Threshold has
been reached
TsD01 NJL Event Log 90% Full 1 623 00 000
Extend Close Time by Area TsD26 Nriaa/idiiii/
tihhmmCE
Auto-arm Time Extended 1 464 aa uuu
Extra Point Tpppp NriaaXEpppp Maintenance Alert 1 393 aa ppp
Fail To Close by Area TsssE NriaCl Failed to Close 1 454 aa 000
Fail to Open by Area TsssE NriaOl Failed to Open 1 453 aa 000
Fire Alarm Fspppp NriaaFApppp Fire 1 110 aa ppp
Fire Cancel \iiii Nriaa/idiiiiFC Cancel 1 406 aa uuu

Bosch B4512 Specifications

General

Control Panel Type	Hybrid
Wired Zones	8
Outputs	2
Programmable Outputs	2
Onboard Ethernet	Yes
Cellular Communication	Optional
Series	B Series
Partitions	2
Type	Control Panel
Model	B4512
Manufacturer	Bosch
Input Voltage	16.5 VAC
Communication Formats	Contact ID, SIA
Power Supply	16.5 VAC
Backup Battery	12 V, 7 Ah
Operating Temperature	0°C to +50°C
Weight	1.5 kg
Compatibility	Bosch accessories
