Bosch B4512 Installation Manual

Control Panels Appendix | en 139
Bosch Security Systems, Inc. Installation Manual 2018.07 | 16 | F.01U.287.180
Panel event Modem4 code
D6500 mode
Modem4 code
Bosch SIA mode
Contact ID event Contact ID code
Restoral from Alarm Rpppp NriaaBHpppp Burglary Restore 3 130 aa ppp
Restoral from Ground Fault Rspppp NriaaBRpppp Ground Fault Restore 3 310 01 000
RF Interference TsD08 NpiddddXQ RF RCVR Jam 1 344 00
1
zzz
RF Interference Restore RsD08 NpiddddXH RF RCVR Jam Restore 3 344 00
1
zzz
RF Transmitter Hss001 NriaaFRpppp Maintenance Alert Restore 3 393 aa ppp
RF Transmitter Low Battery Tspppp NriaaXTpppp RF Low Battery 1 384 aa ppp
RF Transmitter Low Battery
(Key Fob)
TsD10 NidiiiiXT Battery Test Failure 1 309 00 uuu
RF Transmitter Low Battery
(Key Fob) Restore
RsD10 NidiiiiXR Battery Test Restore 3 309 00 uuu
RF Transmitter Low Battery
Restore
Rspppp NriaaXRpppp RF Low Battery 3 384 aa ppp
RF Transmitter Maintenance Gss001 NriaaFTpppp Maintenance Alert 1 393 aa ppp
ROM Checksum Fail AsD12 NYX ROM Checksum bad 1 304 00 000
SDI Device AC Fail TsssDt NpiddddEP Exp. Module AC Loss 1 342 00
1
zzz
SDI Device AC Fail Restore RsssDt NpiddddEQ Exp. Module AC Restore 3 342 00
1
zzz
SDI device is missing TssssD NpiddddET Expansion Module Failure 1 333 00 000
SDI device is restored RssssD NpiddddER Expansion Module Failure
Restore
3 333 00 000
SDI Device Low Battery TsssDt NpiddddEBbb Exp. Module Low Batt. 1 338 00
1
zzz
SDI Device Low Battery
Restore
RsssDt NpiddddEVbb Exp. Module Batt. Restore 3 338 00
1
zzz
SDI Device Missing TsssDt NpiddddEM Exp. Module Failure 1 333 00
1
zzz
SDI Device Missing Battery TsssDt NpiddddEBbb Exp. Module Low Batt.
Restore
3 338 00
1
zzz
SDI Device Missing Battery
Restore
RsssDt NpiddddEVbb Exp. Module Low Batt.
Restore
3 338 00
1
zzz
SDI Device Missing Restore RsssDt NpiddddEN Exp. Module Failure
Restore
3 333 00
1
zzz
SDI Device Over Current TsssD NYI PS Over Current 1 312 00
1
zzz
SDI Device Over Current
Restore
RsssD NYJ PS Over Current Restore 3 312 00
1
zzz
SDI Device Tamper TsssD NES Exp. Module Tamper 1 341 00
1
zzz
SDI Device Tamper Restore TsssD NES Exp. Module Tamper
Restore
3 341 00
1
zzz
