Bosch B4512 Installation Manual

138 en | Appendix Control Panels
2018.07 | 16 | F.01U.287.180 Installation Manual Bosch Security Systems, Inc.
Panel event Modem4 code
D6500 mode
Modem4 code
Bosch SIA mode
Contact ID event Contact ID code
Personal Notification
Communication Trouble
Restore
NsB01 NpiddddYK Communication Trouble
Restore
3 350 0 zzz
Phone Line Missing 1 TsssB NLT1 Telco 1 Fault 1 351 00 000
Phone Line Restored 1 RsssB NLR1 Telco 1 Fault Restore 3 351 00 000
Popex Bus Fault TsssD NYI PS Over Current 1 312 00 ZZZ
Popex Bus Fault Restore RsssD NYJ PS Over Current Restore 3 312 00 ZZZ
Popex Invalid Popit TsssD NYI PS Over Current 1 312 00 ZZZ
Popex Invalid Popit Restore RsssD NYJ PS Over Current Restore 3 312 00 ZZZ
Popex Low Voltage TsssD NYI PS Over Current 1 312 00 ZZZ
Popex Low Voltage Restore RsssD NYJ PS Over Current Restore 3 312 00 ZZZ
Programming Started TsssF NiduuuuTS System Shutdown 1 308 00 iii
Programming Finished RsssF NiduuuuTE System Shutdown Restore 3 308 00 iii
RAM Fail with RPS or
Installer Services Portal
programming tool (available
in Europe, Middle East,
Africa, and China)
TsF02 NRA Unsuccessful access 1 413 00 000
Re-Boot NsD14t NRR System Reset 1 305 00 000
Relay Reset by Sked NsD20 NaikkkROrrrr Sounder/Relay Reset 3 320 00 000
Relay Reset by User NsD18 NidiiiiROrrrr Sounder/Relay Reset 3 320 00 000
Relay Set by Sked NsD19 NaikkkRCrrrr Sounder/Relay Set 1 320 00 000
Relay Set by User NsD28 NidiiiiRCrrrr Sounder/Relay Set 1 320 00 000
Remote Reset - System was
reset by RPS or Installer
Services Portal programming
tool (available in Europe,
Middle East, Africa, and
China)
NsD11 NRN System Reset 1 305 00 000
Remove User’s Key Fob
(Assign Card Event)
NsD30 NidiiiiDAuuuu Local Only Local Only
Replace Sensor Tpppp NriaaBTpppp Maintenance Alert 1 393 aa ppp
Replace Sensor Restore Rpppp NriaaBRpppp Maintenance Alert Restore 3 393 aa ppp
Replace User’s Key Fob
(Assign Card Event)
NsD30 NidiiiiDAuuuu Local Only Local Only
Restoral Rpppp NriaaBRpppp Sensor Trouble Restore 3 380 aa ppp

Bosch B4512 Specifications

General

Control Panel Type	Hybrid
Wired Zones	8
Outputs	2
Programmable Outputs	2
Onboard Ethernet	Yes
Cellular Communication	Optional
Series	B Series
Partitions	2
Type	Control Panel
Model	B4512
Manufacturer	Bosch
Input Voltage	16.5 VAC
Communication Formats	Contact ID, SIA
Power Supply	16.5 VAC
Backup Battery	12 V, 7 Ah
Operating Temperature	0°C to +50°C
Weight	1.5 kg
Compatibility	Bosch accessories
