SmartFlex
Continued from previous page
Item Description
Tx Overruns Lost sent packets because of overload.
Uptime Indicates how long the connection to the cellular network has
been established.
Table 1: Mobile Connection
3.1.2 Primar y LAN, Secondary LAN, Tertiary LAN, WiFi
Items displayed in this part have the same meaning as items in the previous part. More-
over, the MAC Address item shows the MAC address of the corresponding router’s interface
(Primary LAN – eth0, Secondary LAN – eth1, Tertiary LAN – eth2, WiFi – wlan0). Visible
information depends on configuration (see 4.1 or 4.5).
If the router is equipped with PoE PSE board, there is also information about it in the
Primary LAN or Secondary LAN section (see table below for description).
Item Description
PoE PSE Status
• Disabled – PoE PSE is disabled in the Primary LAN or Sec-
ondary LAN configuration form.
• Undervoltage – Undervoltage, i.e. a lower voltage than the
nominal operating voltage.
• Overcurrent – Overcurrent, i.e. a higher current than the
permissible positive difference of the nominal current.
• Idle – PoE PSE is enabled, but currently not used.
• Class 0 – Power level (classification unimplemented)
• Class 1 – Power level (very low power)
• Class 2 – Power level (low power)
• Class 3 – Power level (mid power)
• Class 4 – Power level (high power)
PoE PSE Power Power of PoE PSE [W]
PoE PSE Voltage Voltage of PoE PSE [V]
PoE PSE Current Current of PoE PSE [mA]
Table 2: PoE PSE information
8
