SmartFlex
4.8 Static Routes
Static routes can be specified on the Static Routes configuration page. A static route
provide fixed routing path through the network. It is manually configured on the router and
must be updated if the network topology was changed recently. Static routes are private
routers unless they are redistributed by a routing protocol. Static routes configuration form is
shown on figure 30.
Figure 30: Static Routes Configuration
The description of all items is listed in table 34.
Item Description
Enable IPv4 (IPv6)
static routes
If checked, static routing functionality is enabled. Active are only
routes enabled by the checkbox in the first column of the table.
Destination Network The destination IP address of the remote network or host to which
you want to assign a static route.
Mask or Prefix
Length
The subnet mask of the remote network or host IP address.
Gateway IP address of the gateway device that allows for contact between
the router and the remote network or host.
Metric Metric definition, means number rating of the priority for the route
in the routing table. Routes with lower metrics have higher priority.
Interface Select an interface the remote network or host is on.
Table 34: Static Routes configuration
63
