SmartFlex
4.3 Mobile WAN Configuration
The SmartFlex SR300 (LAN version) does not display the Mobile WAN configuration
option.
Select the Mobile WAN item in the Configuration menu section to enter the cellular network
configuration page. See Mobile WAN Configuration page in Figure 23.
4.3.1 Connection to Mobile N etwork
If the Create connection to mobile network checkbox is checked, then the router will au-
tomatically attempt to establish a connection after booting up. You can specify the following
parameters for each SIM card separately.
Item Description
Carrier Network carrier selection (for SmartStart SR305 router only).
APN Network identifier (Access Point Name).
Username The user name used for logging on to the GSM network.
Password The password used for logging on to the GSM network.
Authentication Authentication protocol used in the GSM network:
• PAP or CHAP – The router selects the authentication method.
• PAP – The router uses the PAP authentication method.
• CHAP – The router uses the CHAP authentication method.
IP Mode Specifies the version of IP protocol used:
• IPv4 – IPv4 protocol is used only (default).
• IPv6 – IPv6 protocol is used only.
• IPv4/IPv6 – IPv4 and IPv6 independent dual stack is enabled.
IP Address For use in IPv4 and IPv4/IPv6 mode only. Specifies the IPv4 address
of the SIM card. You manually enter the IP address only when mobile
network carrier has assigned the IP address.
Phone Number Specifies the telephone number which the router dials for a GPRS or
CSD connection. The router uses the default telephone number
*99***1 #.
Operator Specifies the carrier code. You can specify this parameter as the PLNM
preferred carrier code.
Continued on next page
39
