B+B SmartWorx SmartFlex - GRE Tunnel Configuration Example

SmartFlex
GRE tunnel configuration:
Configuration A B
Remote IP Address 10.0.0.2 10.0.0.1
Remote Subnet 192.168.2.0 192.168.1.0
Remote Subnet Mask 255.255.255.0 255.255.255.0
Table 45: GRE Tunnel Configuration Example
Examples of different options for configuration of GRE tunnel can be found in the application
note GRE Tunnel [7].
89
