SmartFlex
Continued from previous page
Item Description
Masquerade outgoing packets Activates/deactivates the network address tran-
slation function.
Table 38: Remote Access Configuration
Attention! Enable remote HTTP access on port activates the redirect from HTTP to
HTTPS protocol only. The router doesn’t allow unsecured HTTP protocol to access
the web configuration. To access the web configuration, always check the Enable re-
mote HTTPS access on port item. Never enable the HTTP item only to access the web
configuration from the Internet (configuration would not be accessible from the Internet).
Always check the HTTPS item or HTTPS and HTTP items together (to set the redirect
from HTTP).
Use the following parameters to set the routing of incoming data from the WAN (Mobile
WAN) to a connected computer.
Item Description
Send all remaining incoming
packets to default server
Activates/deactivates forwarding unmatched incoming
packets to the default server. The prerequisite for the
function is that you specify a default server in the De-
fault Server IPv4/IPv6 Address field. The router can for-
ward incoming data from a GPRS to a computer with
the assigned IP address.
Default Server IPv4 Address In IPv4 NAT Configuration only. The IPv4 address.
Default Server IPv6 Address In IPv6 NAT Configuration only. The IPv6 address.
Table 39: Configuration of Send all incoming packets to server
4.10.1 Examples of NAT Configuration
Example 1: IPv4 NAT Configuration with Single Device Connected
It is important to mark the Send all remaining incoming packets to default server check
box for this configuration. The IP address in this example is the address of the device behind
the router. The default gateway of the devices in the subnetwork connected to router is the
same IP address as displayed in the Default Server IPv4 Address field. The connected device
replies if a PING is sent to the IP address of the SIM card.
70
