Parameter
Notation
Parameter
Description
Range
Low*B
Range
High*B
Default
Value*C
Unit*E
CJTL
Cold Junction Low Temperature
Calibration Coefficient
-5.0°C
40.0°C
°C
CJG
Cold Junction Gain
Calibration Coefficient
-199.9
199.9
REF1
Reference Voltage1
Calibration Coefficient for RTD1
-199.9
199.9
SR1
Serial Resistance 1 Calibration
Coefficient for RTD1
-199.9
199.9
MA1G
mA input 1 Gain Calibration
Coefficient
-199.9
199.9
REF2
Reference Voltage2
Calibration Coefficient for RTD2
-199.9
199.9
SR2
Serial Resistance 2 Calibration
Coefficient for RTD2
-199.9
199.9
V2G
Voltage input 2 Gain Calibration
Coefficient
-199.9
199.9
MA2G
mA input 2 Gain Calibration
Coefficient
-199.9
199.9
O2L
Output2 Low Calibration Coefficient
0
360.0
O2H
Output 2 High Calibration
Coefficient
0
900.0
SIG1
Point 1 Signal Value of
Special Sensor
-19999
45536
IND1
Point 1 Indication Value of Special
Sensor
-19999
45536
PV
SIG2
Point 2 Signal Value of
Special Sensor
-19999
45536
IND2
Point 2 Indication Value of Special
Sensor
-19999
45536
PV
SIG3
Point 3 Signal Value of
Special Sensor
-19999
45536
IND3
Point 3 Indication Value of Special
Sensor
-19999
45536
PV
SIG4
Point 4 Signal Value of
Special Sensor
-19999
45536
IND4
Point 4 Indication Value of Special
Sensor
-19999
45536
PV
SIG5
Point 5 Signal Value of
Special Sensor
-19999
45536
IND5
Point 5 Indication Value of Special
Sensor
-19999
45536
PV
SIG6
Point 6 Signal Value of
Special Sensor
-19999
45536
IND6
Point 6 Indication Value of Special
Sensor
-19999
45536
PV
SIG7
Point 7 Signal Value of
Special Sensor
-19999
45536
