Brainchild PR10 User Manual

Page 118 of 479
Parameter
Notation
Parameter
Description
Range
Low*B
Range
High*B
Default
Value*C
Unit*E
IND7
Point 7 Indication Value of Special
Sensor
-19999
45536
PV
SIG8
Point 8 Signal Value of
Special Sensor
-19999
45536
IND8
Point 8 Indication Value of Special
Sensor
-19999
45536
PV
SIG9
Point 9 Signal Value of
Special Sensor
-19999
45536
IND9
Point 9 Indication Value of Special
Sensor
-19999
45536
PV
TYPE
Signal Type of Special Sensor
0
3
DATE
Manufacturing Date of
Product
0
3719
NO
Serial Number of Product
1
999
HOUR
Working Hour Value
0
65535
Hour
HRLO
Fractional Hour Value
0
0.9
0.1Hour
ERR1
Historical Error Record 1
0
FFFF
0
ERR2
Historical Error Record 2
0
FFFF
0
DELI
ASCII Input Delimiter
0000
007F
000A
BPL1
OUT1 Bumpless Transfer Value
0
100.00
%
BPL2
OUT2 Bumpless Transfer Value
0
100.00
%
PVHI
Historical Maximum Value of PV
-19999
45536
PV
PVLO
Historical Minimum Value of PV
-19999
45536
PV
CJCL
Sense Voltage of Cold Junction
Calibration Low
31.680
40.320
mV
FILE
Default File Selection
0 *B32
1 *B32
PV
Current Process Value
-19999
45536
PV
SV
Current set point Value
-19999
45536
PV
MV1
Current Output 1 Value
0
100.00
%
MV2
Current Output 2 Value
0
100.00
%
ALM
Contains Conditional Code of
parameters Resolution and Current
Alarm Status
0 *B33
EF7F *B33
DV
Current Deviation (PV-SV)Value
-12600
12600
PV
PV1
IN1 Process Value
-19999
45536
*E5
PV2
IN2 Process Value
-19999
45536
*E6
PB
Current Proportional Band Value
0
500.0°C
(900.0°F)
PV
TI
Current Integral Time
Value
0
4000
Sec
TD
Current Derivative Time
Value
0
1440
Sec
EROR
Current Error Code
0 *B34
40 *B34
PROG
Program Identification Code
Contains Program Number
and Version Number
0 *B35
15.99 *B35
