Brainchild PR10 User Manual

Page 121 of 479
Parameter Value
Display Symbol
Description
1
8BIT
8 Data Bits
5-9 Communication Data Length
*B9: Display Symbol and Description for PARI
Parameter Value
Display Symbol
Description
0
EVEN
Even Parity
1
ODD
Odd Parity
2
NONE
No Parity
5-10 Communication Parity
*B10: Display Symbol and Description for STOP
Parameter Value
Display Symbol
Description
0
1 BIT
One Stop Bit
1
2 BIT
Two Stop Bits
5-11 Communication Stop Bit
*B11: Display Symbol and Description for AOFN
Parameter Value
Display Symbol
Description
0
PV1
Retransmit IN1 Process Value
1
PV2
Retransmit IN2 Process Value
2
P1-2
Retransmit IN1-IN2 Difference Process Value
3
P2-1
Retransmit IN2-IN1 Difference Process Value
4
SV
Retransmit Set Point Value
5
MV1
Retransmit Output1 manipulation Value
6
MV2
Retransmit Output2 manipulation Value
7
DV
Retransmit Deviation(PV-SV) Value
5-12 AOFN Function
*B12: Display Symbol and Description for IN1
Parameter Value
Display Symbol
Description
0
J_TC
J Type Thermocouple
1
K_TC
K Type Thermocouple
2
T_TC
T Type Thermocouple
3
E_TC
T Type Thermocouple
4
B_TC
B Type Thermocouple
5
R_TC
R Type Thermocouple
6
S_TC
S Type Thermocouple
7
N_TC
N Type Thermocouple
8
L_TC
L Type Thermocouple
9
PT.DN
PT 100 Ohms DIN Curve
10
PT.JS
PT100 Ohms JIS Curve
11
4-20
4-20mA Linear Current Input
12
0-20
0-20mA Linear Current Input
13
0-1V
0-1V Linear Voltage Input
14
0-5V
0-5V Linear Voltage Input
15
1-5V
1-5V Linear Voltage Input
16
0-10
0-10V Linear Voltage Input
17
SPEC
Special defined sensor Curve
5-13 IN1 Type
*B13: Display Symbol and Description for IN1U & IN2U
Parameter Value
Display Symbol
Description
0
°C
Degree Celsius Unit
1
°F
Degree Fahrenheit Unit
2
PU
Process Unit
