Brainchild PR10 User Manual

Page 120 of 479
If PVMD=
Range of SP2 same as range of
PV1
IN1
PV2
IN2
P1-2,P2-1
IN1,IN2
5-4 Range of SP2
*B3: Display Symbol and Description of FUNC
Parameter Value
Display Symbol
Description
0
BASC
Basic Function Mode
1
FULL
Full Function Mode
5-5 Mode Selection
*B4: Display Symbol and Description for COMM
Parameter Value
Display Symbol
Description
0
NONE
No Communication Function
1
485
RS-485 Interface
2
232
RS-232 Interface
3
4-20
4-20mA Analog Retransmission Output
4
0-20
0-20mA Analog Retransmission Output
5
0-1V
0-1V Analog Retransmission Output
6
0-5V
0-5V Analog Retransmission Output
7
1-5V
1-5V Analog Retransmission Output
8
0-10V
0-10V Analog Retransmission Output
5-6 Communication Mode
*B5: Display Symbol and Description for PROT
Parameter Value
Display Symbol
Description
0
RTU
Modbus RTU Mode
1
ASCI
Modbus ASCII Mode
2
DNET
DeviceNet Protocol
3
PBUS
Profibus Protocol
4
FBUS
Fieldbus Protocol
5
ABUS
Reserved
6
BNET
Reserved
5-7 Communication Protocol
*B7: Display Symbol and Description for BAUD
Parameter Value
Display Symbol
Description
0
0.3
0.3 Kbits/Second Baud Rate
1
0.6
0.6 Kbits/Second Baud Rate
2
1.2
1.2 Kbits/Second Baud Rate
3
2.4
2.4 Kbits/Second Baud Rate
4
4.8
4.8 Kbits/Second Baud Rate
5
9.6
9.6 Kbits/Second Baud Rate
6
14.4
14.4 Kbits/Second Baud Rate
7
19.2
19.2 Kbits/Second Baud Rate
8
28.8
28.8 Kbits/Second Baud Rate
9
38.4
38.4 Kbits/Second Baud Rate
5-8 Communication Baud Rate
*B8: Display Symbol and Description for DATA
Parameter Value
Display Symbol
Description
0
7BIT
7 Data Bits
