Brainchild PR10 User Manual

Page 127 of 479
Error
Code
Display
Symbol
Error Description
Corrective Action
6
Er 06
Illegal setup values used: OUT2 select
=AL2 but A2FN select NONE
Check and correct setup values of OUT2 and
A2FN. OUT2 will not perform alarm function if
A2FN select NONE.
7
Er 07
Illegal setup values used: Dwell timer
(TIMR) is selected for both A1FN and
A2FN.
Check and correct setup values of A1FN and
A2FN. Dwell timer can only be properly used for
single alarm output.
9
Er 09
Communication error: receive error due
to parity error, framing error, overrun
error, receive buffer full error, frame
check-sum error or receive disturbed
1.Correct the communication software to meet
the protocol requirements
2. Add a terminating resister to the multi- drop
link (RS-485) to minimize the noise.
3. Use twisted pair wire for RS-485 interface
connection to minimize the noise.
4. Check the polarity of RS-485 interface
connection.
10
Er 10
Communication error: bad function code
Correct the communication software to meet the
protocol requirements.
11
Er 11
Communication error: register address
out of range
Don't issue an over- range address of register to
the slave.
12
Er 12
Communication error: access a non-
existent parameter
Don't issue a non- existent parameter to the
slave.
14
Er 14
Communication error: attempt to write a
read only data
Don't write a read only data or a protected data
to the slave.
15
Er 15
Communication error: write a value which
is out of range to a register
Don't write an over- range data to the slave
register.
17
Er 17
Computing error: Illegal (abnormal)
floating point data
Software bug. Return to factory for repair.
18
Er 18
Computing error: Arithmetic result
overflow or underflow
Software bug. Return to factory for repair.
19
Er 19
Computing error: divided by zero
Don't use an equal value for AOLO and AOHI.
20
Er 20
Computing error: Illegal BCD data entry
Software bug. Return to factory for repair.
21
Er 21
Timing error: A to D conversion data
error due to overrun
A to D converter doesn't work properly. Return
to factory for repair.
22
Er 22
Timing error: check-sum error received
during multi-chip communication
procedure
1. Correct the multi-chip communication
software to meet the protocol requirement.
2. Return to factory for repair.
23
Er 23
Timing error: wrong function code
received during multi-chip communication
procedure
1. Correct the multi-chip communication
software to meet the protocol requirement.
2. Return to factory for Repair.
26
AtEr
Fail to perform
auto-tuning function
1. The PID values obtained after auto-tuning
procedure are out of range. Retry auto-tuning.
2. Don’t change set point value during auto-
tuning procedure.
3 .Don’t change Event input state during auto-
tuning procedure.
4. Use manual tuning Instead of auto-tuning.
27
CAER
Incorrect calibration procedure or
tolerance of analog component too big to
meet specified accuracy
1. Pay more attention to the calibration
procedures.
2. Return to factory for repair.
