Error
Code
Display
Symbol
Error Description
Corrective Action
28
CAPE
Memory comparison error, different
value detected in the EEPROM and
mapped RAM
1. Check and correct the wiring and grounding
problems to minimize the system noise.
2. Return to factory for repair.
29
EEPE
EEPROM can't be written correctly
Return to factory for repair.
32
CJER
Cold junction compensation device(s)
malfunction
Return to factory for repair.
33
YYER
Key switch shorted or related PCB circuit
shorted
Return to factory for repair.
34
LLL2
Input 2 ( IN2 ) signal too low
1. Check if the input 2 sensor used is accordant
with IN2 type selection.
2. Check the connection polarity of input 2
sensor.
3. Replace input 2 sensor.
35
HHH2
Input 2 ( IN2 ) signal too high
1. Check if the input 2 sensor used is accordant
with IN2 type selection.
2. Replace input 2 sensor.
36
LLL1
Input 1 ( IN1 ) signal too low
1. Check if the input 1 sensor used is accordant
with IN1 type selection.
2. Check the connection polarity of input 1
sensor.
3. Replace input 1 sensor.
37
HHH1
Input 1 ( IN1 ) signal too high
1. Check if the input 1 sensor used is accordant
with IN1 type selection.
2. Replace input 1 Sensor.
38
SB2E
Input 2 ( IN2 ) sensor break, or input 2
current below 1 mA if 4-20 mA is
selected, or input2 voltage below
0.25V if 1 - 5V is selected
Replace input 2 sensor.
39
SB1E
Input 1 ( IN1 ) sensor break, or input 1
current below 1 mA if 4-20 mA is
selected, or input1 voltage below
0.25V if 1 - 5V is selected
Replace input 1 sensor.
40
ADER
A to D converter or related component(s)
malfunction
Return to factory for repair.
5-32 Error Messages and Corrective Actions
*B35: PROG CODE Description
Parameter
Value
Specified product
0.XX
BTC-2500 controller
1.XX
BTC-4300 controller
2.XX
BTC-9500 controller
3.XX
BTC-8300 controller
4.XX
BTC-4300 controller & Process Control card of PR
5.XX
BTC-7200 controller
6.XX
BTC-9100 controller
7.XX
SM-40A smart panel meter
8.XX
Reserved
9.XX
ST-30A smart transmitter
10.XX
Reserved
