Brainchild PR10 User Manual

Page 415 of 479
Modbus Address
Notation
Register Name
Access
503
C5_EIFN
Event input function
7
0 : None
1 : SP2
2 : PID2
3 : SP.P2
4 : RS.A1
5 : RS.A2
6 : R.A1.2
7 : D.O1
8 : D.O2
9 : D.O1.2
10 : LOCK
R
504
Reserve
Reserve
R
505
C5_SP1
Set point 1
R
506
C5_SP2
Set point 2
R
507
C5_Profile
Profile number
R
508
C5_Segment
Segment number
R
509
C5_Cycle
Cycle remaining for the current loop
R
510
C5_Run
Profile running
R
511
C5_Hold
Profile held
R
512
C5_Up
Running ramp up segment
R
513
C5_Down
Running ramp down segment
R
514
C5_Unit
Current input unit
R
515
C5_ProfileERROR
Profile error
0 : Normal
1 : Holdback timeout
R
516
C6_PV
Current process value
R
517
C6_SV
Current set point Value
R
518
C6_PVMD
PV mode selection
1
0 : PV1
1 : PV2
2 : PV1 - 2
3 : PV2 - 1
R
519
C6_IN1U
IN1 unit selection
2
0 : ℃
1 : ℉
2 : PU
R
520
C6_IN2U
IN2 unit selection
3
0 : ℃
1 : ℉
2 : PU
R
521
C6_MV1
Current output 1 value
R
522
C6_MV2
Current output 2 value
R
523
C6_ALM
Contains conditional code of parameters' resolution and current alarm status
4
R
524
C6_ERROR
Current error code
5
R
525
C6_SPMD
Set point mode selection
6
0 : SP1.2
1 : MIN.R
2 : HR.R
3 : PV1
4 : PV2
5 : PUMP
R
