Brainchild PR10 User Manual

Page 416 of 479
Modbus Address
Notation
Register Name
Access
526
C6_EIFN
Event input function
7
0 : None
1 : SP2
2 : PID2
3 : SP.P2
4 : RS.A1
5 : RS.A2
6 : R.A1.2
7 : D.O1
8 : D.O2
9 : D.O1.2
10 : LOCK
R
527
Reserve
Reserve
R
528
C6_SP1
Set point 1
R
529
C6_SP2
Set point 2
R
530
C6_Profile
Profile number
R
531
C6_Segment
Segment number
R
532
C6_Cycle
Cycle remaining for the current loop
R
533
C6_Run
Profile running
R
534
C6_Hold
Profile held
R
535
C6_Up
Running ramp up segment
R
536
C6_Down
Running ramp down segment
R
537
C6_Unit
Current input unit
R
538
C6_ProfileERROR
Profile error
0 : Normal
1 : Holdback timeout
R
539
C7_PV
Current process value
R
540
C7_SV
Current set point Value
R
541
C7_PVMD
PV mode selection1
0 : PV1
1 : PV2
2 : PV1 - 2
3 : PV2 - 1
R
542
C7_IN1U
IN1 unit selection2
0 : ℃
1 : ℉
2 : PU
R
543
C7_IN2U
IN2 unit selection3
0 : ℃
1 : ℉
2 : PU
R
544
C7_MV1
Current output 1 value
R
545
C7_MV2
Current output 2 value
R
546
C7_ALM
Contains conditional code of parameters' resolution and current alarm status4
R
547
C7_ERROR
Current error code5
R
548
C7_SPMD
Set point mode selection6
0 : SP1.2
1 : MIN.R
2 : HR.R
3 : PV1
4 : PV2
5 : PUMP
R
