Brainchild PR10 User Manual

Page 424 of 479
Modbus Address
Notation
Register Name
Access
1757
C4_SPMD
Set point mode selection
6
0 : SP1.2
1 : MIN.R
2 : HR.R
3 : PV1
4 : PV2
5 : PUMP
R
1759
C4_EIFN
Event input function
7
0 : None
1 : SP2
2 : PID2
3 : SP.P2
4 : RS.A1
5 : RS.A2
6 : R.A1.2
7 : D.O1
8 : D.O2
9 : D.O1.2
10 : LOCK
R
1761
Reserve
Reserve
R
1763
C4_SP1
Set point 1
R
1765
C4_SP2
Set point 2
R
1767
C4_Profile
Profile number
R
1769
C4_Segment
Segment number
R
1771
C4_Cycle
Cycle remaining for the current loop
R
1773
C4_Run
Profile running
R
1775
C4_Hold
Profile held
R
1777
C4_Up
Running ramp up segment
R
1779
C4_Down
Running ramp down segment
R
1781
C4_Unit
Current input unit
R
1783
C4_ProfileERROR
Profile error
0 : Normal
1 : Holdback timeout
R
1785
C5_PV
Current process value
R
1787
C5_SV
Current set point Value
R
1789
C5_PVMD
PV mode selection
1
0 : PV1
1 : PV2
2 : PV1 - 2
3 : PV2 - 1
R
1791
C5_IN1U
IN1 unit selection
2
0 : ℃
1 : ℉
2 : PU
R
1793
C5_IN2U
IN2 unit selection
3
0 : ℃
1 : ℉
2 : PU
R
1795
C5_MV1
Current output 1 value
R
1797
C5_MV2
Current output 2 value
R
1799
C5_ALM
Contains conditional code of parameters' resolution and current alarm
status
4
R
1801
C5_ERROR
Current error code
5
R
