Brainchild PR10 User Manual

Page 425 of 479
Modbus Address
Notation
Register Name
Access
1803
C5_SPMD
Set point mode selection
6
0 : SP1.2
1 : MIN.R
2 : HR.R
3 : PV1
4 : PV2
5 : PUMP
R
1805
C5_EIFN
Event input function
7
0 : None
1 : SP2
2 : PID2
3 : SP.P2
4 : RS.A1
5 : RS.A2
6 : R.A1.2
7 : D.O1
8 : D.O2
9 : D.O1.2
10 : LOCK
R
1807
Reserve
Reserve
R
1809
C5_SP1
Set point 1
R
1811
C5_SP2
Set point 2
R
1813
C5_Profile
Profile number
R
1815
C5_Segment
Segment number
R
1817
C5_Cycle
Cycle remaining for the current loop
R
1819
C5_Run
Profile running
R
1821
C5_Hold
Profile held
R
1823
C5_Up
Running ramp up segment
R
1825
C5_Down
Running ramp down segment
R
1827
C5_Unit
Current input unit
R
1829
C5_ProfileERROR
Profile error
0 : Normal
1 : Holdback timeout
R
1831
C6_PV
Current process value
R
1833
C6_SV
Current set point Value
R
1835
C6_PVMD
PV mode selection
1
0 : PV1
1 : PV2
2 : PV1 - 2
3 : PV2 - 1
R
1837
C6_IN1U
IN1 unit selection
2
0 : ℃
1 : ℉
2 : PU
R
1839
C6_IN2U
IN2 unit selection
3
0 : ℃
1 : ℉
2 : PU
R
1841
C6_MV1
Current output 1 value
R
1843
C6_MV2
Current output 2 value
R
1845
C6_ALM
Contains conditional code of parameters' resolution and current alarm
status
4
R
1847
C6_ERROR
Current error code
5
R
