Brainchild PR10 User Manual

Page 426 of 479
Modbus Address
Notation
Register Name
Access
1849
C6_SPMD
Set point mode selection
6
0 : SP1.2
1 : MIN.R
2 : HR.R
3 : PV1
4 : PV2
5 : PUMP
R
1851
C6_EIFN
Event input function
7
0 : None
1 : SP2
2 : PID2
3 : SP.P2
4 : RS.A1
5 : RS.A2
6 : R.A1.2
7 : D.O1
8 : D.O2
9 : D.O1.2
10 : LOCK
R
1853
Reserve
Reserve
R
1855
C6_SP1
Set point 1
R
1857
C6_SP2
Set point 2
R
1859
C6_Profile
Profile number
R
1861
C6_Segment
Segment number
R
1863
C6_Cycle
Cycle remaining for the current loop
R
1865
C6_Run
Profile running
R
1867
C6_Hold
Profile held
R
1869
C6_Up
Running ramp up segment
R
1871
C6_Down
Running ramp down segment
R
1873
C6_Unit
Current input unit
R
1875
C6_ProfileERROR
Profile error
0 : Normal
1 : Holdback timeout
R
1877
C7_PV
Current process value
R
1879
C7_SV
Current set point Value
R
1881
C7_PVMD
PV mode selection1
0 : PV1
1 : PV2
2 : PV1 - 2
3 : PV2 - 1
R
1883
C7_IN1U
IN1 unit selection2
0 : ℃
1 : ℉
2 : PU
R
1885
C7_IN2U
IN2 unit selection3
0 : ℃
1 : ℉
2 : PU
R
1887
C7_MV1
Current output 1 value
R
1889
C7_MV2
Current output 2 value
R
1891
C7_ALM
Contains conditional code of parameters' resolution and current alarm
status4
R
1893
C7_ERROR
Current error code5
R
