CAI 700M - Page 162

700M HFID 6-2-15
162
ADUF: Flows
Command
Response
Description
_ADUF_K0
_ADUF_s_z.z_y.y
1. Sample Flow
2. Air Flow
3. Fuel Flow
_ADUF_K0_x
_ADUF_S_xflow
Flow of x
AGRD: Polynomial Coefficients
Command
Response
Description
_AGRD_K0_Mn
_AGRD_s_a0_a1_a2_a3_a4
Polynomial coefficients of Channel m Range n
AKAL: Percent Deviations of Last Accepted Calibration
Command
Response
Description
_AKAL_K0_
_AKAL_s_M1_z.z_y.y_x.x_w.w
_M2_z.z_y.y_x.x_w.w
_M3_z.z_y.y_x.x_w.w
_M4_z.z_y.y_x.x_w.w
Percent Deviation of Ranges M1 to M4.
z.z: Zero gas relative to last calibration
y.y: Zero gas absolute to factory calibration
x.x: Span gas relative to last calibration
w.w: Span gas absolute to factory calibration
AAOG: Applied Offsets and Gains
Command
Response
Description
_AAOG_K0_
_AAOG_s_M1_z.z_y.y
_M2_z.z_y.y
_M3_z.z_y.y
_M4_z.z_y.y
Offset and Gain of Range M1 to M4.
z.z: Offset
yy: Gain
AANG: Verifying Zero-Point Deviation During Auto Calibration
Command
Response
Description
_AANG_K0
_AANG_s_M1_z.z_da_dr
_M2_z.z_da_dr
_M3_z.z_da_dr
_M4_z.z_da_dr
Verifying deviations of Ranges M1 to M4
from zero point stored after auto calibration.
Values: measured value (z.z), absolute dev
(da), relative dev (dr).
