CAI 700M - Page 36

700M HFID 6-2-15
36
Screen Name: The name of the active screen the Analyzer is in; in this case the Measure screen.
Second Log On: SEC appears when the second log is enabled. See Data Logging Time.
AK Status Line: When the AK Status line is enabled, it will scroll through the analyzer’s
present state using AK Protocol. See AK Protocol.
Analyzer Mode: The active mode the analyzer is in (THC, CH
4
or THC/CH
4
/NMHC).
Measured Concentration: The current concentration that is displayed on the screen.
Current Range: The range currently being used by the analyzer. Auto Range is indicated by an
A in front of the range number.
Range Limit: The analyzer’s full-scale value of the range currently in use.
Current Time/Active Alarms: Scrolls between Time and Date and any active alarms.
Keypad Status: Indicates how the keypad input is currently being used. F is for functions, N is
for numeric input.
Up and down arrows are used to change the analyzer’s current range.
Shortcut Menu: Scrollable list of shortcut functions available from the Measurement screen.
See the shortcuts below:
Left or right arrows are used to scroll through the shortcut menu.
Measure Mode
Allows the operator to change the analyzer’s mode to THC, CH
4
or THC/CH
4
/NMHC.
Raw Values
An advanced diagnostic tool used for troubleshooting.
