700M HFID 6-2-15
37
Diags
Diagnostic Values is used to view Temperatures, Pressures, EPC Percent Full Scale and
Flows.
Auto Range
Allows operators to turn Auto Range On or Off.
Manual Cal
The Manual Calibration menu allows operators to Zero or Span the analyzer.
Menus
The Menus screen is the starting point for advanced setup and functions.
Standby
When the analyzer is in Standby mode, it closes all valves and turns off the analyzer’s
optional sample pump.
Range Limits
This screen allows operators to customize the analyzer’s ranges.
Span Conc
Operators can change Span gas concentrations for multiple ranges.
CH
4
Factors
Allows operators to set or adjust the CH
4
Correction Factors.
