Enter 196 End
*/$%ENTR* *ZEND*
8. Symbology Settings
8-2-7 Coupon Gs1DataBar Output
When scanning the barcode data of UPC and GS1 Databar at the same time, whether
to only indicate the content of GS1 Databar
*JVD0*
Disable
*JVD1*
Enable
8-2-8 ExtendedCouponCode
Use the following codes to enable or disable UPC-A and EAN-13with Extended
coupon code:
1.
Off: When left on the default setting(Off), the scanner treats Coupon codes and Extended
Coupon Codes as single bar codes
2.
Allow: If you scan the Allow Connection code, when the scanner sees the coupon code
and thewxtended coupon code in a single scan, it transmits both as one
symbology.Otherwise, it transmits the first coupon code it reads
3.
Require: If you scan the Require Concatenation code, the scanner must see and read the
couponcode and extended coupon code in a single read to transmit the data.No
data is output unless both codes are read
*IVC0*
Off
*IVC1*
Allow
To Next Page
