Canmax CM-2D601 - Insertion1 Data

Enter 256 End
*/$%ENTR* *ZEND*
8. Symbology Settings
8-10-11 Insertion1Data
To set up data1 to be inserted
*N5G+*
Pdf417
*BYU+*
MicroPdf417
Procedure:
(A) Scan “Enter” barcode
(B) Scan “Insertion1Data” barcode
(C) Scan parameters from Hexadecimal / Decimal table
(D) Scan “OK“ barcode
(E) Scan “End” barcode
8-10-12 Insertion2DataPosition
To set up the position to insert data2
*P5I+*
Pdf417
*DYW+*
MicroPdf417
Procedure:
(A) Scan “Enter” barcode
(B) Scan “Insertion2DataPosition” barcode
(C) Scan parameters from Hexadecimal / Decimal table
(D) Scan “OK“ barcode
(E) Scan “End” barcode
Type Configuration Length Default Setting
Pdf417 2 NULL
MicroPdf417
2 NULL
Type Configuration Range
Default Setting
Pdf417 0~2750 0
MicroPdf417
0~366 0
8-10-11 Insertion1Data
8-10-12 Insertion2DataPosition
