65
5. Bluetooth Connection Mode Instruction
5-5 A-303 Dongle mode Connection(USB-HID / USB COM)
5-5-1 HID mode
Make sure the scanner is in Bluetooth mode; please refer to chapter
4-2-1 for how to configure in Bluetooth mode.
Make sure the Mode selection code is configured as “5”. Please refer
to chapter 4-2-4-5.
When Bluetooth Connection established, execute any word processing
software, for example: Word, notepad, Excel and etc. to receive to
barcode data.
When connecting scanner and Bluetooth Dongle,
Press and hold the Pairing/delete (small) key until the
blue LED blinking, then push Scan Key into pairing
mode. The scanner will establish the Bluetooth
connection. If connection successful, the Blue LED
indicator will be on. If not, please repeat the above
mention action or check the Bluetooth parameters
setting.
Insert Bluetooth SPP Dongle to PC.
To Next Page
