Enter 197 End
*/$%ENTR* *ZEND*
8. Symbology Settings
8-2-9 Wait Addon Time
Wait for decoding additional code, need to use” Wait Add-on” ; If to get the additional
code in a specified decoding time, then indicate, otherwise do not indicate
*KVE+*
Procedure: Example:
(A) Scan “Enter” barcode
(B) Scan “Wait Addon Time” barcode
(C) Scan parameters from
Hexadecimal / Decimal table
(D) Scan “OK“ barcode
(E) Scan “End” barcode
If configuration is 20 ms, the
parameter value is 20 ms / 1 ms = 20
8-2-10 ConvertUpcaToEan13
When UPC-A Converted to EAN-13 is selected, UPC-A bar codes are converted to 13
digit EAN-13 codes by adding a zero to the front.
*JV40*
Convert
*JV41*
Off
Configuration Range Unit Default Setting
0~500 ms 1 ms 120 ms
8-2-9 Wait Addon Time
8-2-10 ConvertUpcaToEan13
