45
4. Memory / Bluetooth Mode
2. A-303 , A302 Dongle Mode
Mac address configuration, total of 12 digits, Please refer to the HEX ASCII
table (From 0~9, A~F).
Configuration Max. Configurable Length Default Setting
Hexadecimal /
decimal
barcode table
12 digits 000000000000
Procedure:
(1) Enter: (Enter setting)
*/$%ENTR*
(2) “DongleBtMacAddr”
*D6O+*
(3) Scan Hexadecimal/Decimal Barcode table for input parameters.
(4) OK : (Selection confirmed)
*%OK*
(5) End: (Exit setting)
*ZEND*
Example:
Set Remote Mac Address to 001C97FF043A
A. Scan “Enter” barcode
B. Scan “DongleBtMacAddr” barcode
C. Scan parameters from Hexadecimal /decimal barcode table =>“0”, “0”,
“1”,”C”, “9”,”7”, “F”,”F”, “0”,”4”, “3”,”A” ”OK” (Set “Remote Mac Address
“ value to 001C97FF043A)
D. Scan “End” barcode
Note:
If scanner connection mode is “A-303 Dongle” or “A-302 Dongle” mode,
configuration of Mac address does required, and the configuration cannot be
“000000000000”
