9-ACCESSORIES
SettingrangesforMulti-functionauxiliaryhigh-owhydrauliccircuit
ThesettingrangesoftheMulti-functionauxiliaryhigh-owhydrauliccircuitarerelatedtothecircuitmodeselectedby
thespecicpage.Ifbreakerpagehasbeenselected(Single-actingmode),themaximumowratecanbeselected
withinLevel1andLevel10inthetablebelow.Ifcrusherpagehasbeenselected(Double-actingmode),themaximum
owratecanbeselectedwithinLevel1andLevel20inthetablebelow.
Lv.
1pumpow
Lv.
2pumpsow
1
35L/min(9.2USgpm)
11
164L/min(43.3USgpm)
2
39L/min(10.3USgpm)
12
168L/min(44.4USgpm)
3
53L/min(14.0USgpm)
13
182L/min(48.1USgpm)
4
64L/min(16.9USgpm)
14
193L/min(51.0USgpm)
5
75L/min(19.8USgpm)
15
204L/min(53.9USgpm)
6
87L/min(23.0USgpm)
16
216L/min(57.1USgpm)
7
100L/min(26.4USgpm)
17
229L/min(60.5USgpm)
8
111L/min(29.3USgpm)
18
240L/min(63.4USgpm)
9
119L/min(31.4USgpm)
19
248L/min(65.5USgpm)
10
129L/min(34.1USgpm)
20
258L/min(68.2USgpm)
NOTE:intheSingle-actingmode,themessageTHISEXCEEDSTHEALLOWABLEFLOWRATEappearsatthe
bottomofthesettingtabifavalueaboveLevel10isselected.Ifattachmentoperationisanywaystartedwiththis
setting,themessageCHECKFLOWRATEisdisplayed.Stopattachmentoperation,andmakesuretoselectavalue
ofmaximumowratethatdoesnotexceedLevel10.
ThemaximumowrateforBreaker1combinationandthemaximumowrateforCrusher1combinationaresetfrom
factory:
Breaker1:111L/min(29.3USgpm)
Multi-functioncircuit
Crusher1:240L/min(63.4USgpm)
Themaximumworkingpressureofthecircuitcanbesetaccordingtothemodeselectedbythespecicpage.If
breakerpagehasbeenselected(Single-actingmode),themaximumworkingpressurecanbesetwithinthefollowing
range:
Multi-functioncircuit(Breakermode)14.0–34.5MPa(2030.7–5004.2psi)(in0.5increments)
Ifcrusherpagehasbeenselected(Double-actingmode),themaximumworkingpressurecanbesetwithinthefol-
lowingrange:
Multi-functioncircuit(Crushermode)16.0–34.5MPa(2320.8–5004.2psi)(in0.5increments)
ThemaximumworkingpressureforBreaker1combinationandthemaximumworkingpressureforCrusher1com-
binationaresetfromfactory:
Breaker1:14.0MPa(2030.7psi)
Multi-functioncircuit
Crusher1:16.0MPa(2320.8psi)
9-8
