9-ACCESSORIES
SettingrangesforDouble-actingauxiliaryhigh-owhydrauliccircuit
ThemaximumowratefortheDouble-actingauxiliaryhigh-owhydrauliccircuitcanbeselectedwithinthefollowing
range:
Lv.
1pumpow
Lv.
2pumpsow
1
35L/min(9.2USgpm)
11
164L/min(43.3USgpm)
2
39L/min(10.3USgpm)
12
168L/min(44.4USgpm)
3
53L/min(14.0USgpm)
13
182L/min(48.1USgpm)
4
64L/min(16.9USgpm)
14
193L/min(51.0USgpm)
5
75L/min(19.8USgpm)
15
204L/min(53.9USgpm)
6
87L/min(23.0USgpm)
16
216L/min(57.1USgpm)
7
100L/min(26.4USgpm)
17
229L/min(60.5USgpm)
8
111L/min(29.3USgpm)
18
240L/min(63.4USgpm)
9
119L/min(31.4USgpm)
19
248L/min(65.5USgpm)
10
129L/min(34.1USgpm)
20
258L/min(68.2USgpm)
ThemaximumowrateforCrusher1combinationissetfromfactory:
Double-actingcircuit
Crusher1:240L/min(63.4USgpm)
NOTICE:theworkingpressurecanbesetfromtheinstrumentclusteronlyfortheMulti-functionauxiliaryhigh-ow
hydrauliccircuit.FortheSingle-actingcircuitandfortheDouble-actingcircuittheworkingpressureshallbesetman-
ually.
NOTICE:TheworkingpressureoftheDouble-actingauxiliaryhigh-owhydrauliccircuitshallbesetmanuallybythe
portreliefvalvesontherelevantsectionofthecontrolvalve.Thefactorysettingoftheportreliefvalvesis36.3MPa
(5265.3psi).Themaximumsettingoftheportreliefvalvesis36.3MPa(5265.3psi).
