9-ACCESSORIES
SettingrangesforSingle-actingauxiliaryhigh-owhydrauliccircuit
ThemaximumowratefortheSingle-actingauxiliaryhigh-owhydrauliccircuitcanbeselectedwithinthefollowing
range:
Level
1pumpow
1
35L/min(9.2USgpm)
2
39L/min(10.3USgpm)
3
53L/min(14.0USgpm)
4
64L/min(16.9USgpm)
5
75L/min(19.8USgpm)
6
87L/min(23.0USgpm)
7
100L/min(26.4USgpm)
8
111L/min(29.3USgpm)
9
119L/min(31.4USgpm)
10
129L/min(34.1USgpm)
ThemaximumowrateforBreaker1combinationissetfromfactory:
Single-actingcircuitBreaker1:111L/min(29.3USgpm)
NOTICE:theworkingpressurecanbesetfromtheinstrumentclusteronlyfortheMulti-functionauxiliaryhigh-ow
hydrauliccircuit.FortheSingle-actingcircuitandfortheDouble-actingcircuittheworkingpressureshallbesetman-
ually.
NOTICE:theworkingpressureoftheSingle-actingauxiliaryhigh-owhydrauliccircuitshallbesetmanuallybythe
portreliefvalveontherelevantsectionofthecontrolvalve.Thefactorysettingoftheportreliefvalveis36.3MPa
(5265.3psi).Themaximumsettingoftheportreliefvalveis36.3MPa(5265.3psi).
9-6
