Liberty
™
Automated Microwave Peptide Synthesizer
600178 • Revision 5 • October 2009
15
Waste Reservoir:
10” (w) x 16” (d) x 18” (h) [25 cm (w) x 41 cm (d) x 45.72 cm (h)]
(Must be vented into fume hood)
Approximate overall dimensions for Liberty and external reagents:
48” (w) x 24” (d) x 33.5” (h) [122 cm (w) x 61 cm (d) x 85 cm (h)]
Environmental Conditions
The Liberty is designed for indoor used only.
Temperature Range: 50 °F – 85 °F (10 °C – 29 °C)
Relative Humidity Range: 0 – 85%
Inert Gas Source
The Liberty requires an inert gas source (either high purity grade nitrogen or argon) capable of
supplying 25 psi (20 L/min ow) within ten feet (10’)/three meters (3 m) of the right side of the
instrument.
Electrical Requirements
The Liberty requires four (4) dedicated, grounded electrical connections operating at 120 VAC
(110-140 VAC, 60 Hz, 10 Amp @ 120 VAC) (or 240 VAC [202-250 VAC, 50 Hz, 10 Amp @ 240
VAC] where applicable). Specic power requirements (120 VAC vs. 240 VAC) can be found on
the nameplate afxed to the rear of the Liberty instrument.
One (1) electrical connection is required for each of the following components:
Liberty Module power cord
Discover Module power cord
Router power cord
Controller (laptop computer) power cord
NOTE
Five (5) electrical connections are required when using the desktop
computer controller option: Liberty module, Discover module, router,
controller minitower, controller monitor.
NOTE
Optionally, the router can be powered directly from the Liberty Module
without the need for an external electrical connection (using Router-Serial
Power Cable, PN 243290).
