Liberty
™
Automated Microwave Peptide Synthesizer
600178 • Revision 5 • October 2009
95
The Flow Performance window will open. As each pathway is tested, values will 2.
be recorded in the window.
When the test is complete, report these values to your service technician.3.
Click OK to close the window.4.
Diagnostics Screen
The Diagnostics Screen contains a number of reports and manual controls that are not intended
for normal use. In general, the Diagnostics screen should only be used under the advice of a
trained CEM Service Technician.
Commands Tab
The Commands tab allows for the manual execution of all system commands. In addition, the
Read Discover Errors button will detect any rmware errors in the Discover.
Sensors Tab
The Sensors tab displays the current status (on or off) of each sensor on the system. Sensors
are on when they are seeing liquid, as shown by the bright green indicator.
