15. Removal of left-rear wheel ABS sensor harness
15.1. Raise the vehicle by hoister. (Take care of your safety)
15.2. Unplug the left-rear wheel ABS sensor connector.
16. Removal of right-rear wheel ABS sensor harness.
16.1. Raise the vehicle by hoister. (Take care of your safety)
16.2. Unplug the right-rear wheel ABS sensor connector.
17. Removal of reverse radar power harness
17.1. Use a cross head screwdriver to remove the left C-pillar inner
shield.
17.2. Unplug the reverse radar power plug.
18. Removal of the tail door harness’ butt jointed harness.
18.1. Disassemble the left C-pillar inner shield.
18.2. Unplug the tail door harness’ butt jointed harness.
