II. Instructions on Main Connectors
No Connector Name Pins Connection
1 Instrument to interior
2
Anti-sheft module →instrument to
engine
3 Ground
4 ——
5 Ground
6
Fog lights →c200 (instrument to
interior )
7 C200 (instrument to interior )
8 ——
9 C209 (instrument to engine)
10 C209 (instrument to engine)
11 Instrument electric box
12 Instrument to interior (c200)
13 Ignition switch (IGN1)
14 C100 (instrument to front
compartment )
15 Trouble diagnosis socket
16 C209 (instrument to engine)
17 Air bag
18 C209 (instrument to engine)
19 C200 (instrument to interior )
20
C209〔instrument to engine〕
21
C200 〔instrument to interior 〕
22 Headlight switch
23 C209 (instrument to engine)
24 Headlight switch
25
C100〔instrument to front
compartment
〕
26
C100〔
instrument to front compartment
27
C209〔instrument to engine〕
28 Instrument electric box
29 ——
30
C209〔instrument to engine〕
31 Air bag
1 Combination instrument
connector
32
Fog lights switch →instrument to
front compartment
1 Audio system
C200 (instrument to interior )
2 Left loudspeaker
connector
C200(instrument to interior )
Audio system
1 Ground
2 ——
3
C100 〔instrument to front
compartment〕
4 C200(instrument to interior )
3 Fog light switch
connector
5 C200 (instrument to interior )
6 ——
7 ——
8 ——
9 Headlight switch
Instrument electric box
