10
Instrument electric box connector →
instrument electric box
1 Headlight switch
2
C100 〔instrument to front
compartment 〕
3 ——
4 C200 (instrument to interior )
5 Instrument electric box
4 Nightlight switch
connector
6 Ground
1 Instrument electric box
2 Ignition switch (IGN1)
3 C200 (instrument to interior )
5 Brake light switch
connector
4
C209〔instrument to engine〕
1 Ground
2 C200 instrument to interior
3 Speaker
4 Speaker
5 Speaker
6 Speaker
7 C200 (instrument to interior )
8 C200 (instrument to interior )
9 C200 (instrument to interior )
10 ——
11 ANT
13 ——
14 ——
15 C200 (instrument to interior )
6 Audio system connector
16 C200 (instrument to interior )
7 Antenna power
connector
1 ANT
1
C209 〔instrument to engine〕
8 Air-conditioner
thermostat connector
2
C209 〔instrument to engine〕
1 Audio system
C200 (instrument to interior )
9 Right loudspeaker
connector
2 C200 (instrument to interior )
Audio system
