Battery Cell Insulation Tester 11210 User’s Manual
5-6
Hi-Z
nPass
nFail
nA CQ/
nEOT
nEXT
nPass
nFail
nA CQ/
nEOT
nEXT
nFail Before
ACQ
Handler Clear Mode = Hold
LC/IR Test Result: Pass LC/IR Test Result: Fail
X
nPass
nFail
nA CQ/
nEOT
nEXT
nPass
nFail
nA CQ/
nEOT
nEXT
Note
X: Handler Clear Mode doesn’t use with nFail Before ACQ setting when it sets to
Hold.
nFail Before
ACQ
Handler Clear Mode = Auto
Handler Auto Clear Time = 5ms~9999ms (T)
LC/IR Test Result: Pass LC/IR Test Result: Fail
Low
nPass
nFail
nACQ/
nEO T
nEXT
T
nPass
nFail
nACQ/
nEO T
nEXT
T
Hi-Z
nPass
nFail
nA CQ/
nEOT
nEXT
T
nPass
nFail
nA CQ/
nEOT
nEXT
T
