4.2.2 Execution in V Step Mode
After the settings of Start V, End V and Run time are done, tap “ ” to confirm and start the
execution. Tap “ ” again to abort.
4.2.2.1 Running V Step Mode
Tap “ ” to execute it and the screen will appear as Figure 4-20 shows.
Figure 4-20
When V Step Mode is executed:
1. Start Volt: It is the start voltage setting of V Step Mode.
2. End_Volt: It is the end voltage setting of V Step Mode.
3. Elapse Time: It is the executed time of V Step Mode. The time format is
HOUR:MIN:SEC and the maximum display is 99 hours 59 minutes and 59.99 seconds.
