Chroma 62000D Series User Manual

Programmable Bidirectional DC Power Supply 62000D Series
Operating and Programming Manual
3-40
3. Touch the upper left corner to enter into Menu page.
4. Tap “MEAS. & Setup” to return to the main page.
3.2.4.4 Calibration
Chroma 62000D Series DC power supplies have 6 calibration functions:
1. HOST V: the actual voltage output (CV mode) and its measurement accuracy.
2. HOST I: the actual current output (CC mode) and its measurement accuracy.
3. APG V SET: the actual voltage output in analog voltage control mode.
4. APG I SET: the actual current output in analog current control mode.
5. APG V MEA: the accuracy of analog V Monitor.
6. APG I MEA: the accuracy of analog I Monitor.
In “Configuration” page, select “Calibration” and it will appear as Figure 3-62 shows.
Figure 3-62
The DC power supply should be calibrated annually. For further
requirements, please contact Chroma to arrange for calibration again.
The voltage default calibration points of 62000D Series models are 3%,
50%, or 90% of Vmax.
The current default calibration points of 62000D Series models are ±3%,
±50%, or ±90% of Imax.
3.2.4.4.1 Voltage Output and Measurement Calibration
The recommend DMM for calibrations are shown in Table 3-5. Ensure the DMM is within its
calibration validity period before calling the power supply.
