Chroma 62000D Series User Manual

Programmable Bidirectional DC Power Supply 62000D Series
Operating and Programming Manual
2-6
Max Input Current:
Model
Vin
62060D-100
62120D-100
62180D-100
200Vac
16 A
32 A
50A
380Vac
13A
24A
36A
480Vac
10A
19A
27A
(4) Model 62060D-600
Input voltage/frequency range: V
LL
: 380-480V±10% 3~ 4W / 47-63Hz
V
LL
: 200-220V±10% 3~ 4W / 47-63Hz
Maximum input power: 6.66kVA
4.73kVA
(5) Model 62120D-600/1200
Input voltage/frequency range: V
LL
: 380-480V±10% 3~ 4W / 47-63Hz
V
LL
: 200-220V±10% 3~ 4W / 47-63Hz
Maximum input power: 13.3kVA
9.46kVA
(6) Model 62180D-600/1200/1800
Input voltage/frequency range: V
LL
: 380-480V±10% 3~ 4W / 47-63Hz
V
LL
: 200-220V±10% 3~ 4W / 47-63Hz
Maximum input power: 20kVA
14.2kVA
Max Input Current:
Model
Vin
62060D-600
62120D-
600/1200
62180D-
600/1200/1800
200Vac
15A
30A
45.5A
380Vac
10A
20A
30A
480Vac
8A
16A
24A
2.3.2 Input Connection
(1) The input power connector is located at the right of rear panel.
(2) The power line must be rated at least 105°C.
(3) The power cable width must be 8AWG at least.
(4) Assembly

see Figure 2-1 (a)~(d) and execute the following steps:
a. Secure the power cable and input terminal with a screwdriver.
b. Insert the AC power connector to the AC terminal and secure protection cover.
c. Secure the grounding terminal to the grounding copper stud on the chassis (use a
M4*0.7 flange nut).
d. Install the anti-pulling device to prevent the AC power connecting terminal from
falling off.
