1. The LAN STATUS is displayed automatically in the following 5
types:
CONNECTED: It means the network is connected.
CONNECTING. . . .: It means the network is connecting.
NONE CONNECT: It means the network is not connected.
SETTING. . . .: It means the network is under setting.
ETHERNET MODULE FAIL: It means the network module is fail.
2. The ETHERNET IP address is 0~255. In ETHERNET setting,
DHCP=ON will get the address automatically and DHCP=OFF will
get the address manually. Once the IP address is set, it needs to
set APPLY=YES for the address to be in effect.
3.2.4.1.3 GPIB
This DC power supply supports remote operation via GPIB function. It is necessary to set the
GPIB address before operating remotely.
1. In “Interface” page, select GPIB to enter the power supplies GPIB Address as shown in
Figure 3-45.
