Extended decimal format including NRf and MIN, MAX.
MIN and MAX is the high and low limit of parameter.
5.3.3 Boolean Data Format
The <Boolean> parameter uses the form ON|OFF only.
5.3.4 Character Data Format
The character strings returned by query command are shown in either of the following forms:
<CRD> Character Response Data: character string with maximum length of 12.
<SRD> String Response Data: character string.
5.3.5 Basic Definition
5.3.5.1 Command Tree Structure
The commands of the DC power supply are based on a hierarchical structure, also known as
a tree system. In order to obtain a particular command, the full path to that command must
be specified. This path is represented in the structure by placing the highest node in the
farthest left position of the hierarchy. Lower nodes in the hierarchy are indented in the
position to the right, below the parent node.
5.3.5.2 Program Headers
Program headers are key words that identify the command. They follow the syntax described
in section 5.6 of IEEE 488.2. The DC power supply accepts characters in both upper and
lower case without distinguishing the difference. Program headers consist of two distinctive
types, common command headers and instrument-controlled headers.
