Manual Operation
3-13
Figure 3-17
3.2.3.3 Basic Setting
This function allows you to set the brightness of backlight, language, buzzer, time and date.
In Menu page, tap “System Setup” and select “Basic Setting”, the screen will appear as
Figure 3-18 or Figure 3-19 shows.
1. Tap Backlight to set its brightness.
1. There are 3 selections for BRIGHTNESS: HIGH /NORMAL/
DIMMED, the default is HIGH.
2. The lower backlight brightness, the longer the display panel life.
Thus, it is suggested to turn the backlight brightness to DIMMED
when the device is doing burn-in to prolong the product life of VFD
display.
2. Tap Language to set the desired language.
3. The buzzer sounds when the touch panel or the rotary knob on the front panel is tapped
or turned to remind user. It can be turned off if it is not necessary. (The default is ON.)
1. BUZZER has two options: ON / OFF.
2. When the BUZZER is set to ON, press any key or turn the rotary
knob will beep once to remind user.
3. When the BUZZER is set to ON and the BUZZER will beep
continuously if system protection occurs to remind user.
4. When BUZZER is set to OFF then it will not beep in any situation.
4.
Swipe the “Basic Setup” page left to set “Time” and “Date” in the format of hh:mm:ss
and yyyy-mm-dd as shown in Figure 3-19.
