Chroma 62000D Series User Manual

Manual Operation
3-1
3. Manual Operation
3.1 Introduction
The DC power supply can be operated manually or remotely via GPIB/CAN (option) or USB
or APG interface which is described in Chapter 5 and section 3.2.4.1. Refer to the manual
operation for using the front touch panel or rotary knob to input data described in this
chapter.
The operation mode defaults to manual mode whenever power to the
supply is turned on.
3.2 Menu for Setup
The Menu provides you various settings for configuring the system functions of DC power
supply. The functions include:
1. Meas. & Setup
:
To set output voltage, current and power parameters.
2. Output Setup
:
To set various output parameters including voltage/current slew rate
and etc.
3. System Setup
:
To set the display panel, various protections, time and factory
defaults.
4. Program Seq.
:
To set LIST MODE & V_STEP MODE.
5. Advance
:
To set advanced functions (not supported yet).
6. Configuration
:
To set the communication interface, serial/parallel settings, power on
status, and calibration.
The Menu screen is shown in Figure 3-1 with a complete function tree as shown in Figure
3-2.
Figure 3-1
