Removing and Installing SMC PC Cards

▀ Removing PC Cards

▄ ASR 5000 Installation Guide

212

Step 6 Align the PC Card slot cover over the open slot.

Step 7 Use the two screws that you removed in step 2 of this procedure and a Phillips #1 screwdriver to fasten the PC Card slot

cover.
