Chapter 2 Cisco Catalyst Blade Switch 3120 for HP Cisco IOS Commands
show mls qos maps
Dscp-inputq-threshold map:
d1 :d2 0 1 2 3 4 5 6 7 8 9
--------------------------------------------------------------------
0 : 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01
1 : 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01
2 : 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01
3 : 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01
4 : 02-01 02-01 02-01 02-01 02-01 02-01 02-01 02-01 01-01 01-01
5 : 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01 01-01
6 : 01-01 01-01 01-01 01-01
Cos-outputq-threshold map:
cos: 0 1 2 3 4 5 6 7
------------------------------------
queue-threshold: 2-1 2-1 3-1 3-1 4-1 1-1 4-1 4-1
Cos-inputq-threshold map:
cos: 0 1 2 3 4 5 6 7
------------------------------------
queue-threshold: 1-1 1-1 1-1 1-1 1-1 2-1 1-1 1-1
Dscp-dscp mutation map:
Default DSCP Mutation Map:
d1 : d2 0 1 2 3 4 5 6 7 8 9
---------------------------------------
0 : 00 01 02 03 04 05 06 07 08 09
1 : 10 11 12 13 14 15 16 17 18 19
2 : 20 21 22 23 24 25 26 27 28 29
3 : 30 31 32 33 34 35 36 37 38 39
4 : 40 41 42 43 44 45 46 47 48 49
5 : 50 51 52 53 54 55 56 57 58 59
6 : 60 61 62 63
Related Commands Command Description
mls qos map Defines the CoS-to-DSCP map, DSCP-to-CoS map,
DSCP-to-DSCP-mutation map, IP-precedence-to-DSCP map,
and the policed-DSCP map.
mls qos srr-queue input cos-map Maps CoS values to an ingress queue or maps CoS values to a
queue and to a threshold ID.
mls qos srr-queue input dscp-map Maps DSCP values to an ingress queue or maps DSCP values to
a queue and to a threshold ID.
mls qos srr-queue output cos-map Maps CoS values to an egress queue or maps CoS values to a
queue and to a threshold ID.
mls qos srr-queue output dscp-map Maps DSCP values to an egress queue or maps DSCP values to
a queue and to a threshold ID.
