Cisco Catalyst 3120 Command Reference Guide

2-740
Cisco Catalyst Blade Switch 3120 for HP Command Reference
OL-12248-01
Chapter 2 Cisco Catalyst Blade Switch 3120 for HP Cisco IOS Commands
vlan (global configuration)
Table 2-38 describes the rules for configuring VLANs.
Table 2-37 Valid Commands and Syntax for Different Media Types
Media Type Valid Syntax
Ethernet name vlan-name, media ethernet, state {suspend | active}, said said-value, mtu
mtu-size, remote-span, tb-vlan1 tb-vlan1-id, tb-vlan2 tb-vlan2-id
FDDI name vlan-name, media fddi, state {suspend | active}, said said-value,
mtu mtu-size, ring ring-number, parent parent-vlan-id, tb-vlan1 tb-vlan1-id,
tb-vlan2 tb-vlan2-id
FDDI-NET name vlan-name, media fd-net, state {suspend | active}, said said-value, mtu
mtu-size, bridge bridge-number, stp type {ieee | ibm | auto}, tb-vlan1
tb-vlan1-id,
tb-vlan2 tb-vlan2-id
If VTP v2 mode is disabled, do not set the stp type to auto.
Token Ring VTP v1 mode is enabled.
name vlan-name, media tokenring, state {suspend | active}, said said-value,
mtu mtu-size, ring ring-number, parent parent-vlan-id, tb-vlan1 tb-vlan1-id,
tb-vlan2 tb-vlan2-id
Token Ring
concentrator
relay function
(TrCRF)
VTP v2 mode is enabled.
name vlan-name, media tokenring, state {suspend | active}, said said-value,
mtu mtu-size, ring ring-number, parent parent-vlan-id, bridge type {srb | srt},
are are-number, ste ste-number, backupcrf {enable | disable},
tb-vlan1 tb-vlan1-id, tb-vlan2 tb-vlan2-id
Token Ring-NET VTP v1 mode is enabled.
name vlan-name, media tr-net, state {suspend | active}, said said-value,
mtu mtu-size, bridge bridge-number, stp type {ieee | ibm}, tb-vlan1 tb-vlan1-id,
tb-vlan2 tb-vlan2-id
Token Ring
bridge relay
function (TrBRF)
VTP v2 mode is enabled.
name vlan-name, media tr-net, state {suspend | active}, said said-value,
mtu mtu-size, bridge bridge-number, stp type {ieee | ibm | auto},
tb-vlan1 tb-vlan1-id, tb-vlan2 tb-vlan2-id
Table 2-38 VLAN Configuration Rules
Configuration Rule
VTP v2 mode is enabled, and you
are configuring a TrCRF VLAN
media type.
Specify a parent VLAN ID of a TrBRF that already exists in the
database.
Specify a ring number. Do not leave this field blank.
Specify unique ring numbers when TrCRF VLANs have the same
parent VLAN ID. Only one backup concentrator relay function
(CRF) can be enabled.
VTP v2 mode is enabled, and you
are configuring VLANs other than
TrCRF media type.
Do not specify a backup CRF.
