PurposeCommand or Action
Example:
Device# copy running-config
startup-config
Related Topics
Example: Defining the IP Multicast Boundary to Deny Auto-RP Information, on page 158
Configuring Candidate BSRs (CLI)
You can configure one or more candidate BSRs. The devices serving as candidate BSRs should have good
connectivity to other devices and be in the backbone portion of the network.
This procedure is optional.
SUMMARY STEPS
1.
enable
2.
configure terminal
3.
ip pim bsr-candidate interface-id hash-mask-length [priority]
4.
end
5.
show running-config
6.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode.enable
Step 1
Example:
Device> enable
•
Enter your password if prompted.
Enters the global configuration mode.configure terminal
Example:
Device# configure terminal
Step 2
Configures your device to be a candidate BSR.
ip pim bsr-candidate interface-id
hash-mask-length [priority]
Step 3
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3650 Switches)
OL-29890-01 141
Configuring PIM
Configuring PIMv2 BSR

Cisco Catalyst 3650 Specifications

General

Switching Capacity	160 Gbps
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Device Type	Switch
Form Factor	Rack-mountable
Layer	Layer 3
DRAM	4 GB
Flash Memory	4 GB
Operating System	Cisco IOS XE
Model	Catalyst 3650
Ports	24 or 48 10/100/1000 Ethernet ports
Stacking	Yes
Power over Ethernet (PoE)	Yes
Power Supply Options	350W AC
VLANs	4094
