Configuration Examples for PIM Dense Mode State Refresh
Originating Processing and Forwarding PIM Dense Mode State Refresh Control
Messages Example
The following example is for a PIM router that is originating, processing, and forwarding PIM Dense Mode
State Refresh control messages on Fast Ethernet interface 0/1/0 every 60 seconds:
ip multicast-routing distributed
interface FastEthernet0/1/0
ip address 172.16.8.1 255.255.255.0
ip pim state-refresh origination-interval 60
ip pim dense-mode
Related Topics
Configuring PIM Dense Mode State Refresh, on page 343
PIM Dense Mode State Refresh Overview, on page 342
Processing and Forwarding PIM Dense Mode State Refresh Control Messages
Example
The following example is for a PIM router that is just processing and forwarding PIM Dense Mode State
Refresh control messages on Fast Ethernet interface 1/1/0:
ip multicast-routing
interface FastEthernet1/1/0
ip address 172.16.7.3 255.255.255.0
ip pim dense-mode
Related Topics
Configuring PIM Dense Mode State Refresh, on page 343
PIM Dense Mode State Refresh Overview, on page 342
Additional References
Related Documents
Document TitleRelated Topic
“Configuring Basic IP Multicast” module
The PIM Dense Mode State Refresh feature is an
extension of the PIM Version 2 multicast routing
architecture
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3650 Switches)
OL-29890-01 345
IP Multicast Optimization: PIM Dense Mode State Refresh
Configuration Examples for PIM Dense Mode State Refresh
