Cisco Catalyst 3650

DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode.enable
Step 1
Example:
Device> enable
•
Enter your password if prompted.
Enters global configuration mode.configure terminal
Example:
Device# configure terminal
Step 2
Creates a standard access list.
access-list access-list-number {deny |
permit} source [source-wildcard]
Step 3
•
For access-list-number, the range is 1 to 99.
Example:
Device(config)# access-list 16 permit
•
The deny keyword denies access if the conditions are matched.
•
The permit keyword permits access if the conditions are matched.
225.0.0.0 0.255.255.255
•
For source, specify the multicast group to which the threshold will
apply.
•
(Optional) For source-wildcard, enter the wildcard bits in dotted
decimal notation to be applied to the source. Place ones in the bit
positions that you want to ignore.
The access list is always terminated by an implicit deny statement for
everything.
Specifies the threshold that must be reached before moving to
shortest-path tree (spt).
ip pim spt-threshold {kbps | infinity}
[group-list access-list-number]
Step 4
Example:
Device(config)# ip pim spt-threshold
•
For kbps, specify the traffic rate in kilobits per second. The default
is 0 kbps.
Because of device hardware limitations, 0 kbps is the only
valid entry even though the range is 0 to 4294967.
Note
infinity group-list 16
•
Specify infinity if you want all sources for the specified group to
use the shared tree, never switching to the source tree.
•
(Optional) For group-list access-list-number, specify the access
list created in Step 2. If the value is 0 or if the group list is not used,
the threshold applies to all groups.
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3650 Switches)
152 OL-29890-01
Configuring PIM
Delaying the Use of PIM Shortest-Path Tree (CLI)
